24V 200Ah Lithium Battery
PPGlob provides a lightweight 24V LiFePO4 battery with extended power and faster charging, ensuring you can stay on the water all day with ease.
24V 200Ah Lithium Battery
- Rated Voltage(V): 25.6V
- Rated Capacity(Ah): 200
- Rated power(Wh): 5120
- Max charge voltage(V): 29.2
- Max charge current: 100A
- Max contine current: 100A
- Peak discharge current(≦10S): 200A
- Specs(±2mm): 595*330*300mm
High energy density & grade A cells: PPGlob top grade 24V LiFePO4 battery, made with premium grade A cells, offers unmatched energy density. Equivalent to group 8D size, it delivers a 5120Wh capacity at just 85.54 lbs. These high-capacity cells ensure superior performance and long lifespan, providing extended runtime for your applications.
Supports max. 4P2S battery system: PPGlob 25.6V 200Ah batteries can be expanded to max 8 batteries system that have 4 batteries in parallel and 2 parallel sets in series as a 51.2V 800Ah LiFePO4 battery system. The max. energy is 40.96kWh. With high quality grade A cells and dedicated BMS, the 25.6V 200Ah battery can provide a 3 years life time and serve long for your system. Making it perfect for your solar system or home back-up power system.
6000+ cycle life & 3 years service life: The grade A battery cells can provide over 6000 times cycle times under 100% DOD. Requiring almost no maintenance process and low maintenance fee, perfect for long terms usage for energy storage purpose. Providing a long and reliable power source for your system. Making it able to service as energy storage unit for more than 3 years.
| Nominal Voltage: | 25.6V | Nominal Capacity: | 200Ah |
|---|---|---|---|
| Nominal Energy: | 5120Wh | Max Charging Voltage: | 29.2V |
| Max Charging Current: | 100A | Float Charging Voltage: | 27.2~27.6V |
| Continue Discharge Current: | 100A max | Peak Discharge Current: | 200A (10 seconds) |
| Max Load Power: | 2560W | Discharge Cut-off Voltage: | 21.6V |
| Charge Temperature: | 0~+55℃ | Discharge Temperature: | -20~+60℃ |
| Work Humidity: | <95%R.H | Lifespan(25℃, 0.5C, 100% DOD) | >6000 |
| Battery Cell Combination: | 8S | 24V 200Ah battery dimension: | 595*330*300mm |
| Waterproof Class: | IP65 | Weight: | 42Kg |
Application for 24V 200Ah lifepo4 battery
Upgrade your energy storage with our 24V 200Ah LiFePO4 battery, the ideal deep cycle replacement for various applications:
Marine and Boating:
Reliable power for trolling motors, navigation systems, and onboard electronics.
Lightweight design enhances boat performance and fuel efficiency.
Long-lasting charge ensures all-day adventures on the water.
Recreational Vehicles (RVs):
Powers all your RV appliances, including lights, refrigerators, and entertainment systems.
Quick charging capabilities mean less downtime between trips.
High cycle life ensures consistent performance over many seasons.
Solar Energy Storage:
Perfect for storing solar power for off-grid and backup systems.
Efficiently manages energy loads during peak and off-peak hours.
Long lifespan reduces the need for frequent replacements, saving costs in the long run.
Home Backup Power:
Provides reliable backup power during outages.
Seamlessly integrates with home energy management systems.
Ensures essential devices and appliances remain operational during power cuts.
Golf Carts and Electric Vehicles:
Enhances the performance and range of golf carts and small electric vehicles.
Rapid charging and extended cycle life offer more time on the course or the road.
Lightweight battery improves vehicle efficiency and handling.
FAQ
Frequently Ask Questions
The mostly asked questions about 25.2v 200ah deep cycle battery. They are mostly working for lead acid replacement.
Basic Calculation:
To calculate how long the battery will last, you can use the following formula:
Battery Life (hours) = Battery Capacity (Ah) / Load (A)
For a 24V 200Ah battery:
Battery Capacity: 200 Ah
Voltage: 24V
Example Scenarios:
Constant Load Example: If your load is 10 amps:
Battery Life = 200Ah / 10A = 20 hours
Variable Load Example:
If your load varies, calculate the average load over time. For instance, if you have devices drawing 5 amps for 10 hours and 15 amps for the next 5 hours:
Total Load = (5A×10hours) + (15A×5hours) = 50Ah + 75Ah = 125Ah
Battery Life = 200Ah / (125Ah/total time) = 1.6hours / total time
To determine how many solar panels you need to charge a 24V 200Ah battery, you need to consider the battery's energy capacity, the solar panel specifications, and the average sunlight hours available in your location. Here’s a step-by-step guide to calculate it:
1. Calculate the Battery's Energy Capacity,
2. Determine the Solar Panel Output,
3. Calculate Daily Energy Production,
4. Determine the Number of Panels Needed:
