lithium polymer battery suppliers
102535 3.7V 800mAh Battery
PPGlob 102535 3.7V 800mAh polymer battery suitable for many electronics device. Without any scratches, cracks, cauterization, deformations, swelling, leakage.
102535 3.7V 800mAh Polymer Battery
- Lithium battery type: Polymer & pouch
- Rated voltage: 3.7V
- Nominal capacity: 800mAh
- Energy: 2.96Wh
- Continue charge current: 1.0C rate
- Continue discharge current: 1.0C rate
- Pulse current: 5.0C rate
- Size: 10*25*35mm
102535 3.7V 800mAh Battery Specs
| 102535 3.7V 800mAh Polymer Battery | |
|---|---|
| Nominal Voltage | 3.7V |
| Nominal Capacity | 800mAh |
| Battery Type | Polymer & Pouch |
| Battery Size | 10*25*35mm |
| PCM | Yes |
| Continue Charge Current | 1C |
| Continue Discharge Current | 1C |
| Weight | 10g |
| Lifespan | 500 (80%) |
| Customization | Yes |
Features for 102535 li ion lithium polymer:
The polymer battery comes equipped with a PCM (protection board) to prevent overcharging, overdischarging, and short circuits. It supports a 5.0C discharge rate with a current of 4A.
During assembly into the final device, double-sided adhesive tape should be used to secure it. Please also consider a possible swelling of up to 8%, so allow for a battery thickness of 10.8mm (10mm * 1.08).
This battery is suitable for electronic beauty instruments, smart wearable devices, GPS trackers, Bluetooth earphones, and other consumer electronics. We can provide JST, Molex, and other female connectors for integration with main devices.
We offer a 1-year warranty with 500 cycles (at 25℃, 0.5C rate, 80% DOD). Please send us an inquiry to discuss the details.
FAQ
Frequently Ask Questions
The mostly asked questions about lithium polymer battery.
Typically, the nominal voltage of a li-polymer battery is 3.7V, with an upper voltage limit of 4.2V and a lower limit of 3V. However, 3.8V is also considered high voltage, and charging at this level can be more efficient.
There are several differences between them. The rated voltage of the first one is 3.7V, while an AA battery has a rated voltage of 1.5V. The typical operating voltage of the first one is around 3.7V, whereas the average voltage of an AA battery is 1.5V. Lastly, their sizes vary: AA batteries have a fixed size, whereas polymer batteries can be square or round.
3.7V is nominal voltage of lithium battery. Its charging voltage is generally 4.2V, and its discharge cut-off voltage is 3.0V.
We suggest a standard charging current of 0.2C, which equals 0.16A. However, it can also handle a charge rate of 1C, which is equivalent to 0.8A.
Get a Quote
Send an inquiry today
Get PPGlob reliable lithium pouch battery. Please try to asnwer below questions.
- What's max capacity you are looking for?
- What's work and max current do you prefer?
- What's the max battery size in the given space?
- What's wire & connector information for your final device?
- What's the final application?
